PRODUCATOR: CONSORT - BELGIA


Model: EVS3100
Dimensiuni gel: 10 x 10 cm
Volum solutie tampon: 400
Volum gel (la 0.5 cm): 6-15 ml
Capacitate proba: 30
Dimensiuni unitate: 17 x 14 x 12 cm
Sistem de racire integrat cu apa

Surse de alimentare compatibile: EV2650
EV3150


Ghid de comanda:
Sistemul complet


Cod catalog	Descriere
EVS3100	Cuva Mini verticala pentru electroforeza 2 seturi de placi din sticla “plain” 1 set de placi din sticla cu crestaturi 2 seturi de distantiere de 0.8 mm 1 baza de turnare 1 extra garnitura de rezerva pentru camera superioara cu sol tampon 1 placa “dummy” 2 piepteni: 10 probe, 0.8 mm grosime


Piepteni

Cod catalog	Descriere	Volumul de proba
EVS3100-C6-0.8	0.8 mm grosime, 6 probe	142 μl
EVS3100-C10-0.8	0.8 mm grosime, 10 probe	73 μl
EVS3100-C12-0.8	0.8 mm grosime, 12 probe	55 μl
EVS3100-C6-1.5	1.5 mm grosime, 6 probe	266 μl
EVS3100-C10-1.5	1.5 mm grosime, 10 probe	136 μl
EVS310-C12-1.5	1.5 mm grosime, 12 probe	103 μl



Piepteni Microtiter

Cod catalog	Descriere	Volumul de proba
EVS3100-CMT9-0.8	0.8 mm grosime, 9 probe Mc	84 μl
EVS3100-CMT9-1.5	1.5 mm grosime, 9 probe MC	160 μl



Model: EVS3200 – cuva verticala pentru electroforeza, model Wide


Caracteristici tehnice:
Dimensiuni gel: 20 x 10 cm
Volum solutie tampon: 800
Volum gel (la 0.5 cm): 15 – 30 ml
Capacitate proba: 72
Dimensiuni unitate: 28 x 15 x 13 cm
Sistem de racire cu apa – integrat

Surse de alimentare compatibile:
EV2650
EV3150


Ghid de comanda – Sistemul Complet:

Cod catalog	Descriere
EVS3200	Cuva verticala pentru electroforeza, model “wide” 2 seturi de placi din sticla “plain” 2 seturi din placi din sticla, cu crestaturi 4 seturi de distantiere de 0.8 mm 1 extra garnitura 1 placa “dummy” 2 piepteni: 15 probe, 0.8 mm grosime 2 piepteni: 20 probe, 0.8 mm grosime



Piepteni:

Cod catalog	Descriere	Volumul de proba
EVS3200-C10-0.8	0.8 mm grosime, 10 probe	239 μl
EVS3200-C15-0.8	0.8 mm grosime, 15 probe	144 μl
EVS3200-C20-0.8	0.8 mm grosime, 20 probe	97 μl
EVS3200-C25-0.8	0.8 mm grosime, 25 probe	69 μl
EVS3200-C10-1.5	1.5 mm grosime, 10 probe	449 μl
EVS3200-C15-1.5	1.5 mm grosime, 15 probe	271 μl
EVS3200-C20-1.5	1.5 mm grosime, 20 probe	182 μl
EVS3200-C25-1.5	1.5 mm grosime, 25 probe	129 μl



Piepteni Microtiter

Cod catalog	Descriere	Volumul de proba
EVS3200-CMT18-0.8	0.8 mm grosime, 18 probe MC	78 μl
EVS3200-CMT36-1.5	1.5 mm grosime, 36 probe MC	156 μl
EVS3200-CMT18-0.8	0.8 mm grosime, 18 probe MC	32 μl
EVS3200-CMT36-1.5	1.5 mm grosime, 36 probe MC	64 μl



EVS3300- Cuva verticala pentru electroforeza – Model “maxi”

Caracteristici tehnice:
Dimensiuni gel: 20 x 20 cm
Volum solutie tampon: 1300
Volum gel (la 0.5 cm): 25 – 49 mL
Capacitate proba: 50
Dimensiuni unitate: 30 x 24 x 16 cm
Sistem de racire cu apa integrat

Surse de alimentare recomandate:
EV2650
EV3150

Ghid de comanda – Sistemul Complet:

Cod catalog	Descriere
EVS3300	Cuva verticala pentru electroforeza, model Maxi 2 seturi de placi din sticla “plain” 2 seturi de placi din sticla cu crestaturi 4 seturi de distantiere de 0.8 mm 1 baza de turnare 1 extra garniture de rezerva 1 placa “dummy” 2 piepteni: 15 probe, 0.8 mm grosime 2 piepteni: 20 probe, 0.8 mm grosime



Piepteni

Cod catalog	Descriere	Volumul de proba
EVS3300-C10-0.8	0.8 mm grosime, 10 probe	239 μl
EVS3300-C15-0.8	0.8 mm grosime, 15 probe	144 μl
EVS3300-C20-0.8	0.8 mm grosime, 20 probe	97 μl
EVS3300-C25-0.8	0.8 mm grosime, 25 probe	69 μl
EVS3300-C10-1.5	1.5 mm grosime, 10 probe	449 μl
EVS3300-C15-1.5	1.5 mm grosime, 15 probe	271 μl
EVS3300-C20-1.5	1.5 mm grosime, 20 probe	182 μl
EVS3300-C25-1.5	1.5 mm grosime, 25 probe	129 μl



Piepteni “preparative”

Cod catalog	Descriere	Volum de proba
EVS3300-PREP-1.5	Pipetene model “Preparative” 1.5 mm grosime	4885 μl/115 μl



Model: EVS1100


Caracteristici tehnice:
Dimensiuni placa: 10 x 10 cm
Dimensiuni gel: 7.5 x 8 cm
Numar de geluri: 1 pana la 4
Volum solutie tampon: 250 Ml pana la 1200 ml
Capacitate proba: 80 (20 pe gel)
Dimensiuni unitate: 19 x 13 x 15 cm

Surse de alimentare recomandate:
EV1450
EV2310

Ghid de comanda:
Sistem complet:

Cod catalog	Descriere
EVS1100-SYS	Cuva verticala pentru electroforeza, model Mini, 2 seturi de placi din sticla si distantiere de 1 mm, pachet de racire, placa “dummy”, baza de turnare 2 piepteni: 12 probe, 1 mm grosime, 12 probe



Piepteni

Cod catalog	Descriere	Volum Proba
EVS1100-C5-0.8	0.75 mm grosime, 5 probe	70 μl
EVS1100-C9-0.8	0.75 mm grosime, 9 probe	35 μl
EVS1100-C10-0.8	0.75 mm grosime, 10 probe	30 μl
EVS1100-C12-0.8	0.75 mm grosime, 12 probe	25 μl
EVS1100-C20-0.8	0.75 mm grosime, 20 probe	15 μl
EVS1100-C5-1.0	1 mm grosime, 5 probe	100 μl
EVS1100-C9-1.0	1 mm grosime, 9 probe	50 μl
EVS1100-C10-1.0	1 mm grosime, 10 probe	40 μl
EVS1100-C12-1.0	1 mm grosime, 12 probe	35 μl
EVS1100-C20-1.0	1 mm grosime, 20 probe	20 μl
EVS1100-C5-1.5	1.5 mm grosime, 5 probe	140 μl
EVS1100-C9-1.5	1.5 mm grosime, 9 probe	70 μl
EVS1100-C10-1.5	1.5 mm grosime, 10 probe	60 μl
EVS1100-C12-1.5	1.5 mm grosime, 12 probe	50 μl
EVS1100-C20-1.5	1.5 mm grosime, 20 probe	30 μl
EVS1100-C5-2.0	2 mm grosime, 5 probe	200 μl
EVS1100-C9-2.0	2 mm grosime, 9 probe	100 μl
EVS1100-C10-2.0	2 mm grosime, 10 probe	80 μl
EVS1100-C12-2.0	2 mm grosime, 12 probe	70 μl
EVS1100-C20-2.0	2 mm grosime, 20 probe	40 μl



Piepteni “Preparative”

Cod catalog	Descriere	Volum de proba
EVS1100-P1-0.8	0.75 mm grosime, prep 1, marker 1	500 μl
EVS1100-P1-1.10	1 mm grosime, prep 1, marker 1	650 μl
EVS1100-P1-1.5	1.5 mm grosime, prep 1, marker 1	1000 μl
EVS1100-P1-2.0	2 mm grosime, prep 1, marker 1	1300 μl



Pipeteni “Microtiter”

Cod catalog	Descriere	Volum de proba
EVS1100-CMT8-0.8	0.75 mm grosime, 8 probe MC	40 μl
EVS1100-CMT16-0.8	0.75 mm grosime, 16 probe MC	20 μl
EVS1100-CMT16-1.0	1 mm grosime, 16 probe MC	25 μl
EVS1100-CMT8-1.5	1.5 mm grosime, 8 probe MC	80 μl
EVS1100-CMT16-1.5	1.5 mm grosime, 16 probe MC	40 μl
EVS1100-CMT8-2.0	2 mm grosime, 8 probe MC	120 μl
EVS1100-CMT16-2.0	2 mm grosime, 16 probe MC	50 μl



Model: EVS1200


Dimensiuni placa: 20 x 10 cm
Dimensiuni gel: 18 x 8 cm
Numar de geluri: 1 pana la 4
Volum solutie tampon: 600 ml pana la 2800 ml
Capacitate proba: 192 (48 pe gel)
Dimensiuni unitate: 26 x 16 x 16 cm





Surse de alimentare recomandate: EV2310 si EV2650

Ghid de comanda: Sistemul complet

Cod catalog	Descriere
EVS1200-SYS	Cuva verticala Mini – wide, 2 seturi de placi din sticla cu distantiere 1 mm, pachet de racire, placa “dummy”, baza de turnare, 2 pipteni: 12 probe, 1 mm grosime, 24 probe



Piepteni

Cod catalog	Descriere	Volum Proba
EVS1200-C5-0.8	0.75 mm grosime, 5 probe	160 μl
EVS1200-C10-0.8	0.75 mm grosime, 10 probe	80 μl
EVS1200-C24-0.8	0.75 mm grosime, 24 probe	30 μl
EVS1200-C30-0.8	0.75 mm grosime, 30 probe	25 μl
EVS1200-C48-0.8	0.75 mm grosime, 48 probe	15 μl
EVS1200-C5-1.0	1 mm grosime, 5 probe	200 μl
EVS1200-C10-1.0	1 mm grosime, 10 probe	100 μl
EVS1200-C24-0.1	1 mm grosime, 24 probe	40 μl
EVS1200-C30-1.0	1 mm grosime, 30 probe	35 μl
EVS1200-C48-1.0	1 mm grosime, 48 probe	20 μl
EVS1200-C5-1.5	1.5 mm grosime, 5 probe	320 μl
EVS1200-C10-1.5	1.5 mm grosime, 10 probe	160 μl
EVS1200-C24-1.5	1.5 mm grosime, 24 probe	60 μl
EVS1200-C30-1.5	1.5 mm grosime, 30 probe	50 μl
EVS1200-C48-1.5	1.5 mm grosime, 48 probe	30 μl
EVS1200-C5-2.0	2 mm grosime, 5 probe	400 μl
EVS1200-C10-2.0	2 mm grosime, 10 probe	200 μl
EVS1200-C24-2.0	2 mm grosime, 24 probe	80 μl
EVS1200-C30-2.0	2 mm grosime, 30 probe	70 μl
EVS1200-C48-2.0	2 mm grosime, 48 probe	40 μl



Piepteni Microtiter

Cod catalog	Descriere	Volum de proba
EVS1200-CMT18-0.8	0.75 mm grosime, 18 probe MC	40 μl
EVS1200-CMT36-0.8	0.75 mm grosime, 36 probe MC	20 μl
EVS1200-CMT18-1.0	1 mm grosime, 18 probe MC	50 μl
EVS1200-CMT36-1.0	1 mm grosime, 36 probe MC	25 μl
EVS1200-CMT18-1.5	1.5 mm grosime, 18 probe MC	80 μl
EVS1200-CMT36-1.5	1.5 mm grosime, 36 probe MC	40 μl
EVS1200-CMT18-2.0	2 mm grosime, 18 probe MC	100 μl
EVS1200-CMT36-2.0	2 mm grosime, 36 probe MC	50 μl



Model: EVS1300


Caracteristici generale:
Dimensiuni placa: 20 x 20 cm
Dimensiuni gel: 16 x 17.5 cm
Numar de geluri: 1 pana la 4
Volum solutie tampon: 1200 ml pana la 5600 ml
Capacitate proba: 192 (48 pe gel)
Dimensiuni unitate: 30 x 18 x 27 cm


Surse de alimentare recomandate:
EV2650
EV3150
EV3020

Ghid de comanda – sistemul complet:

Cod catalog	Descriere
EVS1300-SYS	Cuva verticala pentru electroforeza, model Maxi, 2 seturi de placi din sticla cu distantiere de 1 mm, cu racire, placa “dummy”, baza de turnare, 2 pipeteni: 24 probe, 1 mm grosime



Piepteni

Cod catalog	Descriere	Volum proba
EVS1300-C5-0.8	0.75 mm grosime, 5 probe	160 μl
EVS1300-C10-0.8	0.75 mm grosime, 10 probe	80 μl
EVS1300-C24-0.8	0.75 mm grosime, 24 probe	30 μl
EVS1300-C30-0.8	0.75 mm grosime, 30 probe	25 μl
EVS1300-C48-0.8	0.75 mm grosime, 48 probe	15 μl
EVS1300-C5-1.0	1 mm grosime, 5 probe	200 μl
EVS1300-C10-1.0	1 mm grosime, 10 probe	100 μl
EVS1300-C24-1.0	1 mm grosime, 24 probe	40 μl
EVS1300-C30-1.0	1 mm grosime, 30 probe	35 μl
EVS1300-C48-1.0	1 mm grosime, 48 probe	20 μl
EVS1300-C5-1.5	1.5 mm grosime, 5 probe	320 μl
EVS1300-C10-1.5	1.5 mm grosime, 10 probe	160 μl
EVS1300-C24-1.5	1.5 mm grosime, 24 probe	60 μl
EVS1300-C30-1.5	1.5 mm grosime, 30 probe	50 μl
EVS1300-C48-1.5	1.5 mm grosime, 48 probe	30 μl
EVS1300-C5-2.0	2 mm grosime, 5 probe	400 μl
EVS1300-C10-2.0	2 mm grosime, 10 probe	200 μl
EVS1300-C24-2.0	2 mm grosime, 24 probe	80 μl
EVS13000-C30-2.0	2 mm grosime, 30 probe	70 μl
EVS1300-C48-2.0	2 mm grosime, 48 probe	40 μl



Piepteni Microtiter

Cod catalog	Descriere	Volum de proba
EVS1300-CMT18-0.8	0.75 mm grosime, 18 probe MC	40 μl
EVS1300-CMT36-0.8	0.75 mm grosime, 36 probe MC	20 μl
EVS1300-CMT18-1.0	1 mm grosime, 18 probe MC	50 μl
EVS1300-CMT36-1.0	1 mm grosime, 36 probe MC	25 μl
EVS1300-CMT18-1.5	1.5 mm grosime, 18 probe MC	80 μl
EVS1300-CMT36-1.5	1.5 mm grosime, 18 probe MC	80 μl
EVS1300-CMT36-1.5	1.5 mm grosime, 36 probe MC	40 μl
EVS1300-CMT18-2.0	2 mm grosime, 18 probe MC	100 μl
EVS1300-CMT36-2.0	2 mm grosime, 36 probe MC	50 μl
